XLS-2G
These exterior wall covers are ideal for applications where concealment is desired, high wind loads are expected, or lateral shear is required. Infill (provided by others) can be used in various cladding systems, including metal, glass, and stone. XLS-2G joint sizes range from 8" to 24". This re-engineered system has a modular design with lightweight magnets and a compact pulley system, making it easier to install and modify in the field. After an event, the pulley assembly returns the door assembly to the nominal position. This model is only available in 10' lengths.
We’re here to help.
Many of our product solutions offer choices for customization, and we would love to talk you through your options. Also consider checking out our in-stock products, which include our most popular models and colors that are easy to buy online.
Interested in this Product?
We would love to help you! For more information and to purchase, please contact us by requesting a quote below and we will be in touch with you shortly.
We’re here to help.
Many of our product solutions offer choices for customization, and we would love to talk you through your options. Also consider checking out our in-stock products, which include our most popular models and colors that are easy to buy online.
Finishes
-
Mill
Expansion Joint Standard Finish
Performance Data
| Model | Joint Width | Min Opening | Max Opening | Exposed Surface | Blockout Width "A" | Blockout Height | Blockout Width "B" |
|---|---|---|---|---|---|---|---|
| XLS2G-800 | 8.00" (203 mm) | 4.00" (102 mm) | 16.00" (406 mm) | 18.50" (470 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-900 | 9.00" (229 mm) | 4.00" (102 mm) | 18.00" (457 mm) | 19.50" (495 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1000 | 10.00" (254 mm) | 4.00" (102 mm) | 20.00" (508 mm) | 20.50" (521 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1100 | 11.00" (279 mm) | 4.00" (102 mm) | 22.00" (559 mm) | 21.50" (546 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1200 | 12.00" (305 mm) | 4.00" (102 mm) | 24.00" (610 mm) | 22.50" (572 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1300 | 13.00" (330 mm) | 4.00" (102 mm) | 26.00" (660 mm) | 23.50" (597 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1400 | 14.00" (356 mm) | 4.00" (102 mm) | 28.00" (711 mm) | 24.50" (622 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1500 | 15.00" (381 mm) | 4.00" (102 mm) | 30.00" (762 mm) | 25.50" (648 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1600 | 16.00" (406 mm) | 4.00" (102 mm) | 32.00" (813 mm) | 26.50" (673 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1700 | 17.00" (432 mm) | 4.00" (102 mm) | 34.00" (864 mm) | 27.50" (699 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1800 | 18.00" (457 mm) | 4.00" (102 mm) | 36.00" (914 mm) | 28.50" (724 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-1900 | 19.00" (483 mm) | 4.00" (102 mm) | 38.00" (965 mm) | 29.50" (749 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-2000 | 20.00" (508 mm) | 4.00" (102 mm) | 40.00" (1,016 mm) | 30.50" (775 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-2100 | 21.00" (533 mm) | 4.00" (102 mm) | 42.00" (1,067 mm) | 31.50" (800 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-2200 | 22.00" (559 mm) | 4.00" (102 mm) | 44.00" (1,118 mm) | 32.50" (826 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-2300 | 23.00" (584 mm) | 4.00" (102 mm) | 46.00" (1,168 mm) | 33.50" (851 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| XLS2G-2400 | 24.00" (610 mm) | 4.00" (102 mm) | 48.00" (1,219 mm) | 34.50" (876 mm) | 5.25" (133 mm) | 2.00" (51 mm) | 5.25" (133 mm) |
| Model | Joint Width | Min Opening | Max Opening | Exposed Surface | Blockout Width "A" | Blockout Height | Blockout Width "B" |
|---|---|---|---|---|---|---|---|
| XLSC2G-800 | 8.00" (203 mm) | 4.25" (108 mm) | 16.00" (406 mm) | 13.25" (337 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-900 | 9.00" (229 mm) | 4.25" (108 mm) | 18.00" (457 mm) | 14.25" (362 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1000 | 10.00" (254 mm) | 4.81" (122 mm) | 20.00" (508 mm) | 15.25" (387 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1100 | 11.00" (279 mm) | 4.81" (122 mm) | 22.00" (559 mm) | 16.25" (413 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1200 | 12.00" (305 mm) | 4.81" (122 mm) | 24.00" (610 mm) | 17.25" (438 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1300 | 13.00" (330 mm) | 4.81" (122 mm) | 26.00" (660 mm) | 18.25" (464 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1400 | 14.00" (356 mm) | 4.81" (122 mm) | 28.00" (711 mm) | 19.25" (489 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1500 | 15.00" (381 mm) | 4.81" (122 mm) | 30.00" (762 mm) | 20.25" (514 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1600 | 16.00" (406 mm) | 4.81" (122 mm) | 32.00" (813 mm) | 21.25" (540 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1700 | 17.00" (432 mm) | 4.81" (122 mm) | 34.00" (864 mm) | 22.25" (565 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1800 | 18.00" (457 mm) | 4.81" (122 mm) | 36.00" (914 mm) | 23.25" (591 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-1900 | 19.00" (483 mm) | 4.81" (122 mm) | 38.00" (965 mm) | 24.25" (616 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-2000 | 20.00" (508 mm) | 4.81" (122 mm) | 40.00" (1,016 mm) | 25.25" (641 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-2100 | 21.00" (533 mm) | 4.81" (122 mm) | 42.00" (1,067 mm) | 26.25" (667 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-2200 | 22.00" (559 mm) | 4.81" (122 mm) | 44.00" (1,118 mm) | 27.25" (692 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-2300 | 23.00" (584 mm) | 4.81" (122 mm) | 46.00" (1,168 mm) | 28.25" (718 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
| XLSC2G-2400 | 24.00" (610 mm) | 4.81" (122 mm) | 48.00" (1,219 mm) | 29.25" (743 mm) | 5.25" (133 mm) | 2.00" (51 mm) | N/A |
